– Maintains stable vacuum levels throughout the infusion cycle.
– Limits resin migration into vacuum lines.
– Improves process control and reduces rework.
– Quick to position and repeatable across moulds.
– Suitable for internal and peripheral vacuum points.
– Spiral Tube: LDPE 10×12 mm
– Release Film: P31 (28 µm)
– Flow Media Thickness: 2 mm
– Width: 100 mm
– Max Service Temperature: 120 °C
– Roll Length: 20 m
– Colour: Sky blue / white
Resin Break is an integrated resin‑control strip consisting of a 10×12 mm spiral tube wrapped with controlled‑permeability flow media and P31 release film. It stabilises vacuum levels, restricts excessive resin draw at vacuum points, and improves overall infusion control while reducing rework. Designed for reliable performance directly on the mould surface.
